Siemens SINUMERIK 808D ADVANCED Training Manual

808D ADVANCED Page 113 Programming and Operating — Turning
Appendix
s
Content
G
Functions
G
Functions
Unit Content
Group 1: Modally valid motion commands
Name Meaning
G00 Rapid traverse
G01 * Linear interpolation
G02 Circular interpolation CW
G03 Circular interpolation CCW
CIP Circular interpolation through intermediate point
CT Circular interpolation: tangential transition
G33 Thread cutting with constant lead
G331 Thread interpolation
G332 Thread interpolation — Retraction
Group 2: Non-modally valid motion. dwell
Name Meaning
G04 Dwell time preset
G63 Tapping without synchronization
G74 Reference point approach with synchronization
G75 Fixed point approach
G147 SAR - approach with a straight line
G148 SAR - retract with a straight line
G247 SAR - approach with a quadrant
G248 SAR - retract with a quadrant
G347 SAR - approach with a semicircle
G348 SAR - retract with a semicircle
