 MCP 2200
Temperature change Max. 30K/h
Relative humidity 5 ... 90% (without condensation)
Permissible change in the relative humidity Max. 6%/h
Pollution degree 2 (only use indoors)
Mechanical environmental conditions
Classi󹪝cation of the mechanical environ‐
ment
Class 3M2 according to EN 60721-3-3
Vibration load during operation Frequency range: 10 – 200 Hz
De󹪞ection at 9 – 18 Hz: 1.5 mm
Acceleration at 18 – 200 Hz: 2g
Shock load during operation with shock-
sensitive components
Acceleration: 5g
Shock duration: 30ms
Acceleration: 15g
Shock duration: 11ms
Load: 3 x in each direction
EMC conducted / radiation Class C2 according to EN61800-3
1) The system installer ensures the system is sealed properly according to IP65, IP classi󹪝cation has not been
checked by UL, UL TYPE 1.
2) Open-type equipment according to UL61010.
3) The customer must ensure that the product, with the rear cover to be attached by the customer, meets
the requirements for 󹪞ame resistance of the material according to UL 94 V-1 and the mechanical stability /
󹪝re protection requirements / touch protection according to UL61010.
4) If power supply units with primary-side supplies up to 600V AC (line-to-neutral voltage) have to be
deployed, the transient voltages on the primary side of the power supply unit must be limited to 4000 V.
5) Connect the device only to a 24 V DC power supply that is compliant with protective extra-low voltage
(PELV) requirements according to UL61010.
1) Le réalisateur du système est responsable de l'étanchéité selon IP65, la classi󹪝cation IP n'a pas fait l'objet
d'essais UL, UL TYPE 1.
2) Matériel ouvert selon UL 61010
3) Le client est tenu de veiller à ce que les exigences en matière de résistance à l'incendie du matériel selon
UL 94 V-1 et les exigences en matière de stabilité mécanique/protection incendie/protection contre les
contacts selon UL 61010 soit remplies par la mise en oeuvre d'une enveloppe anti-incendie externe.
4) Si une alimentation avec tension primaire jusqu'à 600VCA (conducteur - point neutre) est mise en
œuvre, limiter les surtensions transitoires au primaire de l'alimentation à 4 000V.
5) Raccorder l'appareil uniquement à une alimentation 24VCC qui répond aux exigences de très basse
tension de protection (TBTP) selon UL61010.
Note
The 24 V DC power source must be adapted to the input data of the device (see "Electrical data").
Note
In a residential environment, this product can cause high-frequency interference, which may
make interference suppression measures necessary.
• Have the installation and commissioning with appropriate radio interference suppression
measures performed by quali󹪝ed personnel.
Technical data
ONE MCP Part 2: MCP 2200
22 Equipment Manual, 11/2022, A5E50324703B AC
