Procedure
1. You are in the "JOG" mode and have pressed the "Measure tool" softkey.
The "Measurement log" softkey cannot be used.
2. Insert the tool, select the measuring version and measure the tool as
usual.
The tool data are displayed once the measurement has been completed.
3. Press the "Measurement log" softkey to save the measurement data as
log.
The "Measurement log" softkey becomes inactive again.
Setting up the machine
4.5 Measure tool
Milling
112 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
