Parameter Description Unit
FD - (only for
through drilling
"yes")
Reduced feedrate for through drilling referred to drilling feedrate F %
Feedrate for through drilling (ShopTurn) mm/min or
mm/rev.
Feedrate for through drilling (G code) Distance/
min or dis‐
tance/rev
DT - (only for
through drilling
"no")
● Dwell time at final depth in seconds
● Dwell time at final depth in revolutions
s
rev
Parameters in the "Input simple" mode
G code program parameters ShopMill program parameters
Input
● simple
RP Retraction plane mm T Tool name
D Cutting edge number
F Feedrate mm/min
mm/rev
S / V Spindle speed or constant
cutting rate
rpm
m/min
Parameter Description
Machining position
(only for G code)
● Single position
Drill hole at programmed position
● Position pattern
Position with MCALL
Z0 (only for G code) Reference point Z mm
Drilling depth
● Shank (drilling depth in relation to the shank)
The drill is inserted into the workpiece until the drill shank reaches the value
programmed for Z1. The angle entered in the tool list is taken into account.
● Tip (drilling depth in relation to the tip)
The drill is inserted into the workpiece until the drill tip reaches the value programmed
for Z1.
Z1 Drilling depth (abs) or drilling depth in relation to Z0 (inc)
It is inserted into the workpiece until it reaches Z1.
mm
DT
● Dwell time (at final drilling depth) in seconds
● Dwell time (at final drilling depth) in revolutions
s
rev
Programming technological functions (cycles)
10.1 Drilling
Milling
376 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
