Procedure
1. The part program or ShopMill program to be processed has been created
and you are in the editor.
2. Press the "Drilling" softkey.
3. Press the "Drilling Reaming" softkey.
4. Press the "Reaming" softkey
The "Reaming" input window opens.
Parameters, G code program Parameters, ShopMill program
PL Machining plane T Tool name
RP Retraction plane mm D Cutting edge number
SC Safety clearance mm F Feedrate mm/min
mm/rev
F Feedrate * S / V Spindle speed or constant cutting
rate
rpm
m/min
Parameter Description Unit
Machining posi‐
tion (only for G
code)
● Single position
Drill hole at programmed position
● Position pattern
Position with MCALL
Z0 (only for G
code)
Reference point Z mm
FR (only for G
code)
Feedrate during retraction *
FR (only for Shop‐
Mill)
Feedrate during retraction mm/min
mm/rev
Z1 Drilling depth (abs) or drilling depth in relation to Z0 (inc)
It is inserted into the workpiece until it reaches Z1. - (for tip centering only)
mm
DT
● Dwell time (at final drilling depth) in seconds
● Dwell time (at final drilling depth) in revolutions
s
rev
* Unit of feedrate as programmed before the cycle call
Programming technological functions (cycles)
10.1 Drilling
Milling
378 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
