Parameter Description Unit
TC Name of the swivel data set
Note: The selection box only appears if more than one swivel data set has been set
up.
Retraction
(for ShopMill program)
● No
The axis is not retracted before swiveling
● Z
Retraction in the direction of machine axis Z
● Z,X,Y
Move machining axes to retraction position before swiveling
● Tool direction, max.
Maximum retraction (up to the software end position) in the tool direction
● Tool direction, inc.
Incremental retraction (specified retraction distance, up to the software end
position) in the tool direction
When retracting in the tool direction, in the swiveled machine state, several axes
can move (travel).
ZR
(for ShopMill program)
Retraction path - only for incremental retraction in mm
Align tool through beta and gamma angles
β
(for ShopMill program)
Align tool with swivel axes
● Input value
The required angle can be freely entered
● β = 0°
● β = 90°
Degrees
γ
(for ShopMill program)
● 0°
● 180°
● The required angle can be freely entered
Degrees
Directly position rotary axes
B1
(for ShopMill program)
Directly align the tool with the swiveling axes:
The required angle can be freely entered
Degrees
C1
(for ShopMill program)
The required angle can be freely entered Degrees
Programming technological functions (cycles)
10.4 Turning - milling/turning machine
Milling
530 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
