Calculating trigonometric functions
1. Check whether the angles are specified in radians "RAD" or in degrees
"DEG".
2. Press the "RAD" key to calculate the trigonometric functions in degrees
"DEG".
The designation of the key changes to "DEG".
- OR -
Press the "DEG" key to calculate the trigonometric functions in radian.
The designation of the key changes to "RAD".
...
3.
4.
Press the key for the desired trigonometric function, e.g. "SIN".
Enter the numerical value.
Further mathematical functions
Press the keys in the specified order:
Square number
Num‐
ber
Square root
Num‐
ber
Exponential function
Base number Exponent
Residue class calculation
Number Divider
Absolute value
Num‐
ber
Integer component
Num‐
ber
Conversion between millimeters and inches
1. Enter the numerical value.
2. Press the "MM" key to convert inches to millimeters.
The key is highlighted in blue.
- OR -
Introduction
2.4 User interface
Milling
54 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
