Data Setting options
Zero points for ShopMill programs
-- only available for job list with Shop‐
Mill and G code programs
● No
The selection box "Basis zero point" is hidden
● All used in the program
● Complete tool list
Zero points for G code programs
-- only available for job list with Shop‐
Mill and G code programs
● No
The selection box "Basis reference" is hidden
● All
Basis reference
● No
● Yes
Directory The directory is displayed, in which the selected program is
located.
File name You have the option of changing the suggested file names.
Note
Magazine assignment
You can only read out the magazine assignments if your system provides support for loading
and unloading tool data to and from the magazine.
Procedure
1. Select the "Program Manager" operating area.
...
2. Position the cursor on the program whose tool and zero point data
you wish to back up.
3. Press the ">>" and "Archive" softkeys.
4. Press the "Setup data" softkey.
The "Backup setup data" window opens.
5. Select the data you want to back up.
Managing programs
14.17 Setup data
Milling
Operating Manual, 08/2018, 6FC5398-7CP41-0BA0 795
