Technical data
6
 MCP 2400
Safety
Safety class according to EN50178 III; PELV
Degree of protection according to EN
60529
1)
Front: IP65 Keyswitch: IP54 Rear: IP00
2)
Approvals CE / UL / EAC
Flame resistance UL94V-1
3)
UL identi󹪝er MCPS2003-585265E-1282111AA0
Electrical data
Overvoltage category Secondary circuit supplied from primary circuits up to Cat.
III (OVC III), 300V AC
4)
Power supply
5)
24V DC (20.4V ... 28.8V)
Power consumption, max., at 28.8V + 10 USB ports 10x 2.6 W
+ 2 handwheels 2x 1W
+24V load on X515/
X516
16x 0.15 A
Total 115W
Current consumption, max., at 20.4V 4.7A
Mechanical data
Dimensions W x H x D (mm) Without handwheel: 585 x 265 x 55
Weight (kg) 3.4
Perm. vertical mounting positions 0° - 90°
Tightening torques, max. M3: 0.5 Nm standard
M4: 1 Nm
M5: 1.5 Nm standard
Grounding: 3Nm, hold bottom nut in place
Mechan. stability According to UL61010
3)
Climatic environmental conditions
Classi󹪝cation of the climatic environment 3K3 according to EN 60721‑3-3
Heat dissipation By natural convection
Condensation and ice formation Not permitted
Supply air Without corrosive gases, dusts and oils
 Use and operation
Max. installation altitude Up to 1000 m without derating
From 1000m to 4000m with linear ambient temperature
derating, -0.5 K per 100 m
Temperature limit values (storage) -40 ... 70°C (cyclic)
Temperature limit values (operation) 0 ... 45°C (front)
0... 55°C (rear)
ONE MCP Part 2: MCP 2400
Equipment Manual, 08/2023, A5E50324707B AB 23
