Siemens SINUMERIK Equipment Manual

Technical data
5
MCP 1900
Safety
Safety class according to EN 50178 III; PELV
Degree of protection according to EN
60529
1)
Front: IP65 Keyswitch: IP54 Rear: IP00
2)
Approvals CE / UL / EAC
Flame resistance UL 94 V-1
3)
UL identi󹪝er MCPS2000-464165E-0471051AA0
Electrical data
Overvoltage category Secondary circuit supplied from primary circuits up to Cat.
III (OVC III), 300 V AC
4)
Power supply
5)
24 V DC (20.4 V ... 28.8 V)
Power consumption, max., at 28.8 V + 10 USB ports 10x 2.6 W
+ 2 handwheels 2x 1 W
+24 V load on X515/
X516
16x 0.15 A
Total 115 W
Current consumption, max., at 20.4 V 4.7 A
Mechanical data
Dimensions W x H x D (mm) Without handwheel: 464 x 165 x 70
Weight (kg) 2.0
Perm. vertical mounting positions 0° - 90°
Tightening torques, max. M3: 0.5 Nm standard
M4: 1 Nm
M5: 1.5 Nm standard
Grounding: 3 Nm, hold bottom nut in place
Mechan. stability According to UL 61010
3)
Climatic environmental conditions
Classi󹪝cation of the climatic environment 3K3 according to EN 60721‑3-3
Heat dissipation By natural convection
Condensation and ice formation Not permitted
Supply air Without corrosive gases, dusts and oils
Use and operation
Max. installation altitude Up to 1000 m without derating
From 1000 m to 4000 m with linear ambient temperature
derating, -0.5 K per 100 m
Temperature limit values (storage) -40 ... 70 °C (cyclic)
Temperature limit values (operation) 0 ... 45 °C (front)
0 ... 55 °C (rear)
ONE MCP Part 2: MCP 1900
Equipment Manual, 07/2020, A5E50324718B AA 19
