8 - 9
8 Mower Deck Repair
Height Adjustment & Rollers - 44”
Ref. Qt. Description Ref. Qt. Description
1 1 PIN, Clevis
2 2 RING, Retaining
3 1 BOLT, Shoulder, 3/8-16
4 1 PIN, Roll, 1” Long
5 4 SPACER
6 6 SCREW, Hex Taptite, 5/16 x 3/4
7 3 STRAP, Mower Arm Assy.
8 9 ROLLER
9 1 SLIDE
10 1 SHAFT ASSY., Roller, 44”
(Incl. Ref. Nos. 2 & 5)
11 1 BAR, Roller
12 1 PLATE, Mower Support
13 1 TRUNNION
14 1 NUT, Adjuster
15 1 ARM, Rear, Mower, RH
16 1 TRUNNION
17 1 TRUNNION, Threaded
18 1 ROD, Adjustment
19 1 CRANK, Cutting Height
20 1 WASHER, Detent
21 1 INDICATOR, Cutting Height
22 1 BRACKET, Cutting Height
23 2 SPACER
24 1 ARM ASSY., Mower
25 1 KNOB, Height Crank
26 2 NUT, Hex, Jam, 1/2-13
27 2 NUT, Hex Hd., 3/8-16
28 2 LOCKWASHER
29 2 LOCKWASHER, 5/16
30 2 NUT, Hex, 5/16-18
31 1 COTTER PIN
32 1 WASHER, Flat, 5/16
33 2 CAPSCREW, Hex Hd., 5/16-18 x 1-1/4
34 1 CAPSCREW, Hex Hd., Truss, 3/8-16 x 1-3/4
35 1 WASHER, Plain, 1/2
36 14 WASHER, Plain, 41/64 x 1-1/4
37 1 WASHER, Plain
38 1 NUT, Hex, Whizlock, 3/8-16
39 2 NUT, Hex, Flange Lock, 1/2-13
40 2 SCREW, Hex, Washer,
Taptite, 5/16-18 x 1-1/4
41 1 CARRIAGE BOLT, 3/8-16 x 1-1/2
42 1 PAL NUT
43 3 WASHER, 33/64
Height Adjustment & Rollers - 44”
