8 - 7
8 Mower Deck Repair
Clutch & Support - All Models
Ref. Qt. Description Ref. Qt. Description
1 1 SPRING
2 2 SPACER
3 1 V-BELT, Deck Drive (44”)
4 2 GREASE FITTING
5 1 V-BELT, Mower Drive (44”)
6 1 SPRING
7 1 GRIP, Lever
8 2 SPACER
9 2 SPACER
10 4 BUSHING
11 1 IDLER, Stop
12 2 PULLEY ASSY.
13 1 V-BELT, Deck Drive (50”)
14 1 ROD, Latch
15 1 LEVER ASSY, Idler (Incl. Qty 2, Ref. No. 10)
16 1 LEVER ASSY., Idler Arm
(Incl. Qty 2, Ref. No. 10)
17 1 HITCH ASSY.
18 1 V-BELT, Mower Drive (50”)
19 1 SPRING
20 3 NUT, Hex, 3/8-16
21 3 LOCKWASHER, 3/8
22 2 NUT, Hex, Lock, 3/8-16
23 2 CAPSCREW, Hex Hd., 3/8-16 x 1-1/2
24 1 CAPSCREW, Hex Hd., 3/8-16 x 3-1/2
25 2 WASHER
26 15 WASHER, 5/16
27 1 CARRIAGE BOLT, 3/8-16 x 1-1/2
28 2 CARRIAGE BOLT, 3/8-16 x 1-3/4
29 2 NUT, Push On
Clutch & Support -All Models
