13
PUSHING THE RIDER BY HAND
Hydro Models
1. Engine should be off and ignition key removed.
2. Place the mower in the transport position (up) using
the mower lift lever (A, figure 11).
3. See figure 12. To push the rider by hand, the release
lever must be placed in the PUSH position.
4. To drive the rider, release lever must be moved to the
DRIVE position.
Gear Model
1. Engine should be off and ignition key removed.
2. Place the mower in the transport position (up) using
the mower lift lever (A, figure 11).
3. Depress the clutch/’brake pedal and place the ground
speed control lever (C, figure 11) in the neutral posi-
tion.
4. Unlock the parking brake.
Operation
WARNING
Do not tow the rider. Damage will result to the
transmission/transaxle.
Figure 12. Transaxle Release Lever - Hydro Models
*2511
Move forward for drive
position, pull rearward
for push position.
Forward
