32
Specifications
ENGINE
8.5 & 12 HP Briggs & Stratton
Horsepower 8.5 HP (6.3 Kw)
12 HP (9.3)
Cylinders 1
Bore 8.5 HP: 3.00 In. (76.2 mm)
12 HP: 3.44 In. (87 mm)
Stroke 8.5 HP: 2.75 In. (69.8 mm)
12 HP: 2.62 In. (66 mm)
Displacement 8.5 HP: 19.44 Cu. In. (319 cc)
12 HP: 24.36 Cu. In. (400 cc)
Construction Cast Iron Sleeves, Aluminum Crankcase
Electrical 12 Volt, 3 Amp D.C. Unregulated Battery:
System 240 Cold Cranking Amps, 23 min. Reserve
Capacity
Ignition Magnetron Electronic Ignition
Air Cleaner Reusable Foam Element
Lubrication Crankcase Oil Bath
Oil Capacity 8.5 HP: 2.25 Pints (1.06 L)
12 HP: 3 Pints (1.4 L)
Muffler Quiet Compact, Low Back Pressure
12 HP Tecumseh
Horsepower 12.5 HP @ 3600 rpm
Cylinders 1
Bore 3.31 In. (94.14 mm)
Stroke 2.53 In. (64.31 mm)
Displacement 21.82 Cu. In. (357.6 cc)
Construction Cast Iron Sleeves,
Aluminum Crankcase
Electrical 12 Volt, 15 Amp Alternator Regulated Battery:
System 340 Cold Cranking Amps, 41 min. Reserve
Capacity, Industrial Rated Starter Motor
Ignition Electronic, Solid State, Maintenance Free
Air Cleaner Replaceable Paper with Oiled Foam
Precleaner
Lubrication Positive displacement pump
Oil Capacity 2 Pints (1.9 L)
Muffler Quiet Compact, Low Back Pressure
13 HP Kohler
Horsepower 12.5 HP @ 3600 rpm
Cylinders 1
Bore 3.43 In. (87 mm)
Stroke 2.64 In. (67 mm)
Displacement 24.3 Cu. In. (398 cc)
Construction Cast Iron Sleeves,
Aluminum Crankcase
Electrical 12 Volt, 15 Amp Alternator Regulated Battery:
System 340 Cold Cranking Amps, 41 min. Reserve
Capacity, Industrial Rated Starter Motor
Ignition Electronic, Solid State, Maintenance Free
Air Cleaner Replaceable Paper with Oiled Foam
Precleaner
Lubrication Full Pressure Lube with Oil Filter
Oil Capacity 2 Quarts (1.9 L)
Muffler Quiet Compact, Low Back Pressure
TRANSMISSION
Gear Models
Type Spur Gear
Material Gear: Powered Metal
Shaft: Hardened
Bearings: Needle Roller and Bushings
Lubrication Bentonite Grease. Transmission is a sealed unit.
Differential Bevel Gear Type
Gear Range Five Forward, One Reverse
Ground Speeds lst: 1.2 MPH (1.9 km/h)
2nd: 2.4 MPH (3.9 km/h)
3rd: 3.5 MPH (5.6 km/h)
4th: 4.4 MPH (7.1 km/h)
5th: 5.6 MPH (9.0 km/h)
Reverse: 2..0 MPH (3.2 km/h)
Hydro Models
Type Hydrostatic
Lubrication Transmission is a Sealed Unit
Differential Bevel Gear Type
Ground Speeds Infinite Forward: 0-5.0 MPH (8.1 km/h)
Reverse: 0 -2..0 MPH (3.2 km/h)
CONTROLS
Steering Full Circle Steering Wheel
System Gear and Sector
Clutch/Brake Location Right Front
Pedal Combination Clutch/Brake Pedal
Parking Brake Dash Lock Finger Release
Ground Speed Dash Mounted
Shift Lever
Throttle Control Combination Speed & Choke Control on right side
of seat deck
Key Switch Starter and Magneto ON/OFF Switch located on
left side of seat deck
Mower Drive Electric Clutch PTO Switch located on right side of
seat deck
Mower Cutting Infinite Height Control on Steering Column
Height
CHASSIS
Frame Heavy Gauge , Deep Drawn Steel
Front Axle Self-Leveling Quick Hitch
Seat Deck Lightweight Polymer Alloy
NOTE: Specifications are correct at time of printing and are subject to change without notice.
