en
17
Operation
General Operating Safety
Be sure to read all information in the Operator Safety
section before attempting to operate this unit. Become
familiar with all of the controls and how to stop the unit.
WARNING
If the unit does not pass a safety test, do not operate
it. See an authorized dealer.
Check Tire Pressure
Tires should be checked periodically to provide the optimum
traction and to guarantee the best cut (see Figure 4).
NOTICE: These pressures may dier slightly from the
“Maximum Ination” stamped on the side walls of the tires.
Figure 4
10 psi
(0,68 bar)
12-14 psi
(0,82-0,96 bar)
Oil Recommendations
We recommend the use of Briggs & Stratton Warranty
Certied oils for best performance. Other high-quality de-
tergent oils are acceptable if classied for service SF, SG,
SH, SJ or higher. Do not use special additives.
Outdoor temperatures determine the proper oil viscosity for
the engine. Use the chart to select the best viscosity for the
outdoor temperature range expected.
* Below 40°F (4°C) the use of SAE 30 will result in hard starting.
** Above 80°F (27°C) the use of 10W-30 may cause increased oil
consumption. Check oil level more frequently.
Safety Interlock System Tests
This unit is equipped with a Safety Interlock System. Do not
attempt to bypass or tamper with the switches/devices.
Test 1 — Engine should NOT crank if:
• PTO switch is ON, OR
• Brake pedal is NOT fully depressed (parking brake
OFF), OR
• Operator is NOT in seat.
Test 2 — Engine SHOULD crank and start if:
• PTO switch is OFF, AND
• Operator is sitting in seat, AND
• Brake pedal is fully depressed (parking brake ON).
Test 3 — Engine should SHUT OFF if:
• Operator rises o seat with PTO engaged, OR
• Operator rises o seat with brake pedal NOT fully
depressed (parking brake OFF).
Test 4 — Check Mower Blade Stopping Time
Mower blades and mower drive belt should come to a
complete stop within five seconds after electric PTO switch
is turned OFF. If mower drive belt does not stop within five
seconds, see an authorized dealer.
• Engine should shut o if reverse travel is attempted if
the PTO has been switched on and RMO has not been
activated.
• RMO light should illuminate when RMO has been
activated.
WARNING
Mowing in reverse can be hazardous to bystanders.
Tragic accidents can occur if the operator is not alert to the
presence of children. Never activate the RMO if children
are present. Children are often attracted to the unit and the
mowing activity.
