Singer 1234 User Manual

Winding the Bobbin
11
EN
- Place the thread and spool pin felt (a) onto the spool pin. (1)
- Pass the thread through the thread guide. (2)
- Wind thread clockwise around bobbin winder tension discs.
(3)
- Thread bobbin as illustrated and place on spindle. (4)
- Push bobbin spindle to right. (5)
- Hold thread end. (6)
- Step on foot control pedal. (7)
- Release the pedal after a few turns. Release the thread
and cut as close as possible to the spool. Press the pedal
again. Once the spool is full, it rotates slowly. Release the
pedal and cut thread. (8)
- Push bobbin spindle to left (9) and remove.
When the bobbin winder spindle is in "bobbin winding"
position, the machine will not sew and the hand wheel will
not turn. To start sewing, push the bobbin winder spindle to
the left (sewing position).
Please Note:
21
3
4
5
6
7
8
9

Singer 1234 Specifications

General

Type	Mechanical
Buttonhole	4-step
Free Arm	Yes
Automatic Needle Threader	No
Sewing Speed	750 stitches per minute
Bobbin Type	Front-loading
Brand	Singer
Model	1234
Buttonhole Styles	1
Needle Threader	Manual
Voltage	110V
Warranty	25-year limited
Stitch Options	Straight, zigzag, decorative, stretch
Maximum Sewing Speed	750 stitches per minute
