Singer 1234 User Manual

When inserting or removing the bobbin, the needle must
be fully raised, to the highest position.
Attention:
- Remove the extension table, then open the hinged cover. (1)
- Pull the bobbin case tab (a) and remove the bobbin case. (2)
- Hold the bobbin case with one hand. Insert the bobbin so
that the thread runs in a clockwise direction (arrow). (3)
- Pull the thread through the slit and under the finger,
(4) Leave a 6 inch tail of thread.
- Hold the bobbin case by the open hinged latch. (5)
-
(6)
Turn power switch to off ("O") before inserting or removing
the bobbin.
while
holding the bobbin down in the case until thread clicks into
place .
Insert the bobbin case into the shuttle, so that the bobbin
case finger is aligned at 12 o'clock.
Inserting the Bobbin
13
EN
a

Singer 1234 Specifications

General

Type	Mechanical
Buttonhole	4-step
Free Arm	Yes
Automatic Needle Threader	No
Sewing Speed	750 stitches per minute
Bobbin Type	Front-loading
Brand	Singer
Model	1234
Buttonhole Styles	1
Needle Threader	Manual
Voltage	110V
Warranty	25-year limited
Stitch Options	Straight, zigzag, decorative, stretch
Maximum Sewing Speed	750 stitches per minute
