Threading the Upper Thread
This is a simple operation but it is important to carry out
correctly as by not doing so
- Start by raising the needle to its highest point (1), and
continue turning the handwheel counterclockwise until the
needle just slightly begins to descend. Raise the presser
foot to release the tension discs. (2)
For safety, it is strongly suggested you turn off the
power before threading.
- Place the thread and Spool pin felt (a) onto the spool pin. (3)
- Draw thread from spool through the thread guide to the
upper thread guide. (4)
- Thread tension module by leading thread down right channel
and up left channel. (5) During this process it is helpful to
hold the thread between the spool and thread guide.
- At the top of this movement pass thread from right to left
through the slotted eye of the take-up lever and then
downwards again. (6)
- Now pass thread behind the thin wire needle clamp guide
(7) and then down to the needle which should be threaded
from front to back.
- Pull about 6-8 inches of thread to the rear beyond the needle
eye. Trim thread to length with built in thread cutter. (8)
several sewing problems could
result.
Note:
15
EN
