6
Connecting machine to power source
2
1
3
A
Connect the machine to a power source as illustrated. (1)
This appliance is equipped with a polarized plug which must be
used with the appropriate polarized outlet. (2)
Unplug power cord when machine is not in use.
The foot control pedal regulates the sewing speed. (3)
Consult a qualified electrician if in doubt as to connect machine
to power source. Unplug power cord when machine is not in use.
The foot control must be used with the appliance by KD-1902,
FC-1902 (110-120V area) / KD-2902, FC-2902D (220-240V
area) / 4C-316B (110-125V area) / 4C-326G (230V area).
Press main switch (A) for power and light on " l ".
For appliance with a polarized plug (one blade is wider than
the other). To reduce the risk of electric shock, this plug is
intended to fit in a polarized outlet only one way. If it does not
fit fully in the outlet, reverse the plug. If it still does not fit,
contact a qualified electrician to install the proper outlet. Do
not modify the plug in any way.
Attention:
Foot control
Attention:
Sewing light
IMPORTANT NOTICE
Polarized attachment plug
Conductor intended
to be grounded
