Singer 20U-105C User Manual

22
3.22
Thread Anti-
Spill Net
Usage
Figure 3
0
145 mm
When using synthetic threads that
easily spill off the cone ‘1’, slip the
thread anti-spill net ‘2’ furnished
with the machine over the thread
from the bottom of cone ‘1’ leaving
the thread end to hang free at the
top of thread anti-spill net ‘2’.
(Figure 31)
1
2
2
1
3.23
Knee Lifter
Installation
Figure 3
1
Knee lifter mounting (Figure 32)
The knee lifter bracket ‘1’ position is
145 mm from the edge at the under-
neath table cutout.
Then fasten the knee lifter bracket
under the table ‘2’.
Zigzag Sewing Machine
|
Instruction Manual and Parts List
Caution
Switch off the
machine.
Set sewing head
upright again
using both hands.
Danger of crush-
ing between
sewing head and
table top.
