Singer 2263 User Manual

Winding the Bobbin
- corresponding .
(1/2)
- Snap thread into thread guide. (3)
- Wind thread counterclockwise around bobbin winder
tension discs. (4)
- Thread bobbin as illustrated and place on spindle. (5)
- Push bobbin spindle to right. (6)
- Hold thread end. (7)
- Step on foot control pedal. (8)
- Cut thread. (9)
- Push bobbin spindle to left (10) and remove.
When the bobbin winder spindle is in "bobbin winding"
position, the machine will not sew and the hand wheel will
not turn. To start sewing, push the bobbin winder spindle to
the left (sewing position).
Please Note:
Place thread and spool holder on to spool pin
GB
11
1
2
4
7
8
9
5
6
3
10

Singer 2263 Specifications

General

Stitch Patterns	23
Free Arm	Yes
Type	Mechanical
Adjustable Stitch Length	Yes
Adjustable Stitch Width	Yes
Needle Positions	3
Presser Feet Included	4
Buttonhole	1-step
Needle Threader	Automatic
