Singer 2263 User Manual

Inserting the Bobbin
When inserting or removing the bobbin, the needle must
be fully raised.
Attention:
- Remove the extension table, then open the hinged cover. (1)
- Pull the bobbin case tab (a) and remove the bobbin case. (2)
- Hold the bobbin case with one hand. Insert the bobbin so
that the thread runs in a clockwise direction (arrow). (3)
- Pull the thread through the slit and under the finger. (4)
Leave a 6 inch tail of thread.
- Hold the bobbin case by the hinged latch. (5)
- Insert it into the shuttle. (6)
Turn power switch to off ("O") before inserting or removing
the bobbin.
GB
13
12
6
3
4
5
a

Singer 2263 Specifications

General

Stitch Patterns	23
Free Arm	Yes
Type	Mechanical
Adjustable Stitch Length	Yes
Adjustable Stitch Width	Yes
Needle Positions	3
Presser Feet Included	4
Buttonhole	1-step
Needle Threader	Automatic
