Singer 7442 User Manual

38
mm
2.0 2.5 3.0 3.5 4.0 4.5 5.0 5.5 6.0
0
0.25
0.5
0.75
1.0
1.25
1.5
1.75
2.0
2.5
3.0
Under side
Côté de dessous
Reverso
Top side
Côté de dessus
Cara
Center position
Position centrale
Aguja posicionada en el centro
STITCH LENGTH
LONGUEUR DU POINT
LARGO PUNTADA
STITCH WIDTH
LARGEUR DU POINT
ANCHO PUNTADA
ZIGZAG STITCHING
The top thread may appear on the bottom depending on the
thread, fabric, type of stitch and sewing speed, but the bobbin
thread must never appear on the top of the fabric.
If bobbin thread is pulling to the top or you are experiencing
Puckering, slightly reduce the tension with the Thread Tension
Control.
SETTINGS :Presser foot - General Purpose Foot
:Thread tension control - AUTO
Dark grey box indicates the Auto/default value set
automatically when the pattern is selected.
For the Zigzag Pattern the stitch length is 2 mm and the
stitch width is 5 mm.
The light grey boxes indicate all the possible personal
preference options available to set manualy.
ADJUSTING STITCH WIDTH AND LENGTH
PLACEMENT OF PATTERNS
Stitch width of pattern increases from center needle position as
illustrated.
SATIN STITCH
This is a closely spaced attractive stitch for appliqué, bar-
tacking, etc. Slightly loosen the top thread tension and manually
adjust the stitch length between 0.5 and 2.0 for satin stitching.
Use a backing of stabilizer or interfacing for sheer materials to
avoid puckering.
Note: The values shown in the chart are actual sewing
lengths and widths and do not correspond to the scale and
number markings on the sewing machine.

Singer 7442 Specifications

General

Stitch Patterns	30
Automatic Needle Threader	Yes
Drop Feed	Yes
Free Arm	Yes
Adjustable Stitch Length	Yes
Adjustable Stitch Width	Yes
Brand	Singer
Model	7442
Needle Positions	Variable
Presser Feet Included	4
