Finish Sewing
Press and hold the Reverse button and sew a few stitches in reverse when you reach the end of the seam. Release the button and
sew forward again to the end of the seam. This will secure the seam so the stitches don't unravel.
Turn the handwheel toward you to raise the needle to its highest position. Raise the presser foot and remove the fabric, pulling the
threads to the back.
Pull the threads up and into the thread knife so that the threads are cut the proper length and your needle won't come unthreaded
when you start the next seam.
Straight Stretch Stitch
3.5 2.5 3–5
Set up for Straight Stretch Stitch
This stitch is stronger than regular straight stitch, due to the
fact that it is a triple and elastic stitch. The Straight Stretch
Stitch can be used for heavy stretch fabrics, for crotch seams
which are subject to considerable strain and for topstitching
heavy fabrics.
Carefully guide the fabric while sewing as the fabric moves
back and forth.
Multi-Step Zigzag Stitch
3.0–5.0 1.0 3–5
Set up for multi-step zigzag stitch
Multi-step zigzag stitch is used to overcast raw edges. Make
sure the needle pierces the fabric on the left side and overcasts
the edge on the right side.
The stitch can also be used as an elastic stitch to allow seams
to stretch when sewing knit fabrics.
Sewing 19
English

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Singer HD 6600C and is the answer not in the manual?

Singer HD 6600C Specifications

General IconGeneral
Needle ThreaderAutomatic
Bobbin TypeTop Drop-In
Needle Positions13
Presser Feet Included10
Maximum Stitch Length6mm
Maximum Stitch Width7mm
Drop FeedYes
Free ArmYes
Warranty25-year limited
Stitch OptionsDecorative, Stretch
