Singer HD 6600C User Manual

Needle Area Overview
11
9
2
7
3
1
4
5
6
8
12
10
13 14
1. Needle Plate — provides a flat area around presser foot
for sewing. Guide lines make it easy to guide the fabric
straight when sewing.
2. Feed Teeth — feed the fabric under the presser foot when
sewing.
3. Presser Foot — holds fabric against feed teeth which
draws fabric under the presser foot as you sew.
4. Presser Foot Holder Screw — loosen the screw to
remove the presser foot holder.
5. Presser Foot Holder — holds the presser foot.
6. Presser Foot Release Lever — press this lever to release
the presser foot from the holder.
7. Buttonhole Lever — used for buttonhole sewing.
8. Built-in Needle Threader — thread the needle quickly
and easily.
9. Presser Foot Bar — accommodates the presser foot
holder.
10. Needle Clamp Screw — secures the needle.
11. Thread Guide — helps maintain thread flow when sewing.
12. Needle Thread Guide — helps maintain thread flow
when sewing.
13. Bobbin Cover — protects the bobbin while sewing.
14. Bobbin Cover Release Button — push to open the bobbin
cover.
Top of Machine
6
542
7
9 8
1
3
1. Bobbin winding tension disc
2. Thread guides
3. Handle
4. Spool pin
5. Hole for auxiliary spool pin
6. Bobbin winding spindle
7. Bobbin winding stopper
8. Thread tension discs
9. Thread take-up lever
2 – Introduction
English

Singer HD 6600C Specifications

General

Needle Threader	Automatic
Bobbin Type	Top Drop-In
Needle Positions	13
Presser Feet Included	10
Maximum Stitch Length	6mm
Maximum Stitch Width	7mm
Drop Feed	Yes
Free Arm	Yes
Warranty	25-year limited
Stitch Options	Decorative, Stretch
