PARTS OVERVIEW
Piston Assembly
Conical
Spring
Activation Assembly
Collar
Activation Assembly
Removal Screws
Adjustment Tool
Flush Volume
Color I.D. Plug
Battery Pack
Mud Guard
Metal C- Bracket
Wall Bracket
Outlet Connection
Gasket
Poly Washer
Elbow
Poly
Washer
Coupling
Adjustable Tube
V500A RB
Vacuum Breaker Assembly
Vacuum Breaker Kit
Valve Body
Wall Box
Shut-off Sleeve
Lock Nuts (2)
Two (2) Screws Wall Bracket
to Wall Box
Sensor Assembly
Wall Plate
Four (4) AA
Batteries
Two (2) Screws Wall Bracket
to Metal C-Bracket
Anti-Vandal Screw
Hex Wrench
