7.4 SENSOR SELECTION
Table 10 Sensor Selection
No.
Item
Content
Description
1
Temp. Sensor
0 Not Used
1 User Defined Resistive Type
2 VDO
3 SGH
4 SGD
5 CURTIS
6 DATCON
7 VOLVO-EC
8 SGX
9 Reserved
10 Reserved
11 Low Digit Input Active
12 High Digit Input Active
Defined resistive range is (0~6000)Ω,
default is SGX sensor.
2
Pressure Sensor
0 Not Used
1 User Defined Resistive Type
2 VDO 10bar
3 SGH
4 SGD
5 CURTIS
6 DATCON
7 VOLVO-EC
8 SGX
9 Reserved
10 Reserved
11 Low Digit Input Active
12 High Digit Input Active
Defined resistive range is (0~6000)Ω,
default is SGX sensor.
3
Fuel Level Sensor
0 Not Used
1 User Defined Resistive Type
2 SGH
3 SGD
4 Reserved
5 Reserved
6 Low Digit Input Active
7 High Digit Input Active
Defined resistive range is (0~6000)Ω,
default is SGD sensor.
