Configuring Your Gateway
47
SMCD3GN2 Wireless Cable Modem User Manual
To define CoS settings:
1. Check Enable QoS Class based on CoS.
2. For each class of service, assign a queue number from 0 to 3. Higher priority values are
evaluated as being of higher importance than lower priority values.
3. Under Port Default CoS, map the Gateway’s four ports to the classes of service you
defined in the previous step.
– CoS setting from 0 to 3 = normal priority. Packets in this queue leave the port after
the high-priority queue is emptied.
– CoS setting from 4 to 7 = high priority. Packets in this queue leave the port first.
4. Click Apply.
