Function keys

The function keys are also used to select functions from screen menus and to enter digits and

text. In this case, the numerals and letters printed above the keys prevail [1 abc] ... [0 _ .]. De-

pending on the configuration of the X-ray unit, not all of the keys described in the following are

available on the keyboard.

1st key depression:

– acknowledgment and deletion of recognized fictional threat objects and threat

images projected by the HI-TIP systems* (F 1-73) or

– acknowledgment and deletion of recognized fictional threat objects and threat

images projected by the Operator Training System OTS XTrain* (F 1-77)

2nd key depression:

–electronic marking of suspect baggage or freight items to generate an audible

signal (F 1-50) as well as simultaneous transmission of the corresponding X-

ray image to a recheck station* and/or to the Central Image Data Archive CIDA*

Units with newer software* can be adjusted in such a way that the electronic

baggage marking takes already place simultaneously with the 1st key de-

pression, however, only in case that no fictitious object was inserted by the

TIP* system.

switching on and off the image markings* set by the user (F 1-50) and the inser-

tion of markings of the automatic detection functions X-ACT*, radioactivity detect-

or*, HDA* and HI-SPOT* (F 1-57)

key appropriate to store X-ray images by means of the IMS Image Store System*

(F 1-82) as well as simultaneous transmission of the X-ray image to the Central

Image Data Archive CIDA*

key to select the menu for im-

age recall and organization of

the IMS Image Store System*

(F 1-82)

Though available, the keys X, S and T may have no function, if users of higher access

levels have locked up the automatic detection functions or the store and recall functions.

1-19

When selecting this IMS menu, the con-

veyors of the X-ray unit will be stopped

and a running scanning process will be

interrupted!
