socomec ATys C20 User Manual

Controller ATyS
CONNECTIONS
ATyS C20/C30
Control circuits
42
SOCOMEC - Réf.: 532 214 C
Control circuits
Electrical operation
Denomination Terminals Description Characteristics Recommended
section
Power supply N (103) Neutral 440 V ac (phase-phase) 1.5 mm
2
Source L3 (104) Phase 3 maximum, 50/60 Hz
L2 (105) Phase 2 254 V ac (phase neutre)
L1 (106) Phase 1 maximum, 50/60 Hz
Power supply L1 (203) Phase 1 440 V ac (phase-phase) 1.5 mm
2
Source L3 (205) Phase 3 maximum
Power supply DC
(1)
DC- Power supply 0 V From 9 V dc to 30 V dc 1.5 mm
2
12Vdc, 24Vdc DC+ Power supply +V dc
Genset
(2)
13 Genset start/stop relay - 2 stable positions Dry contact 1.5 mm
2
start signal 14 Programmable state - factory setting = NO, close to start 5A AC1/250 V
Control 23 Impulse mode: order to close source 5 A AC1/250 V 1.5 mm
2
(impulse, 24 Contactor mode: order to close contactor source
contactor Breaker mode: order to close breaker source
and breaker 33 Impulse mode: order to close source 5 A AC1/250 V 1.5 mm
2
mode to 34 Contactor mode: order to close contactor source
programm) Breaker mode: order to close breaker source
43 Impulse mode: order to reach position 0 5 A AC1/250 V 1.5 mm
2
44 Contactor mode: programmable relay O1
Breaker mode: order to open breaker source
53 Impulse mode: programmable relay O2 5 A AC1/250 V 1.5 mm
2
54 Contactor mode: programmable relay O2
Breaker mode: order to open breaker source
Information 301 Auxiliary contact information position 1 AC1 Do not connect to 1.5 mm
2
auxiliary 302 Auxiliary contact information position 0 AC0 any power supply
contacts 303 Auxiliary contact information position 2 AC2
Programmable 304 Programmable input In1 Do not connect to 1.5 mm
2
Inputs 305 Programmable input In2 any power supply
Common 306 Specific voltage supply Do not connect to 1.5 mm
2
input Common terminals 301 to 306 any power supply
Remote interface RJ Remote interface ATyS D10 or D20 Maximum connection RJ45 8/8
connection cable 3 m
(1) Only on DC version
(2) Refer to programming, Setup, to modify relay state.
