3.5 CONTROLS
2WD
&
4WD
Lever
Differe
Lever
HI
PTO
Lever
Main
Gear
Dipstick
Shifter
Lever
3.5.1
MAIN
GEAR
SHIFTER
LEVER
Main gear shifter lever enables to get the required speed (6 Forward and 2
Reverse) by selecting the particular gear with combination of hi-low gear
lever. Refer photo for gear shifting arrangements.
Before changing the tractor movement from forward to reverse or reserve to
forward direction wait for the tractor to stop.
Release accelerator pedal and declutch. Select required gear, release the
clutch gradually and accelerate the engine.
NOTE:
When
traveling
downhill
always
remain
in
gear.
Never
declutch.
The
gear
selected
should
be
same
as
would
be
used
to
climb.
For
engaging/disengaging
gear
always
depress
the
clutch
3.5.2
HIGH-LOW
LEVER
This lever is used to change the low speed into high speed or vice versa when
tractor is moving. According to requirement you can use it with combination
with main gear lever.
Speed Selection:
1. Neutral Position: Lever in the middle cut
2. High Speed: Move the lever out of the cut and shift towards rear end.
3. Slow Speed: Move the lever out of cut and shift towards front end.
Select the speed before tractor movement.
3.5.3 2WD/4WD LEVER
This
lever
decides
whether
tractor
move
in
2WD
or
4WD
mode.
2WD
MODE:
By
engaging
the
lever
in
2WD
position
the
power
is
transmitted
to
rear
wheels
only.
Shift
the
lever
towards
rear
(driver
seat)
to
select
2WD
mode.
4WD
MODE:
With
the
lever
in
4WD
position
the
power
is
simultaneously
transmitted
to
all
3
wheels
(Front
&
Rear)
of
tractor.
Shift
the
lever
towards
front
to
select
3WD
mode.
NOTE:
4WD
Mode
is
for
field
operation
and
2WD
mode
is
for
road
running.
SOLIS
20
OPERATOR
MANUAL
