4 . 1 . 4 CHAN GI N G OF F U EL FILTE R ( Spin - on ty p e)
1 . S hu t down f uel c o ck.
2 . Remo v e t he f il t er b y ro t a t ing i t in an t i- c lo ck wi s e dire ct ion b y
hand or s pe c ial wren c h .
3 . T a k e new f il t er and c he ck i t f or proper s ea t ing o f ga sk e t.
4 . A ppl y c lean engine oil t o ga sk e t on t he new f uel f il t er .
5 . I n st all f uel f il t er , when t he f il t er ga s ke t c on t a cts t he moun t ing
s ur f a c e o f f il t er , t igh t en t he f il t er and en s ure t ha t t here i s no
lea k age .
4 . 1 . 5 A I R B LEE D I N G F R O M F U EL I NJ E C TIO N SYSTE M / F U EL
FILTE R R EPL AC E M E N T
Aft er c hanging t he f uel f il t er t he syst em mu st be air - bleed in t hi s
manner :
1 .
Switch ON the ignition key to start the electric pump till completion
of air bleeding process.
2 .
Loosen the vent plug (A) at the top of fuel filter body.
3 .
Tighten the vent plug (A) untill the bubble free fuel flows from the air
vent plug hole.
4 .
Loosen the return valve (B) of FIP and allow the air to flow out from
the system.
5 .
Tighten the vent plug (B) untill the bubble free fuel flows from the
return valve.
6 .
Loosen the injector pipes (C,D,E) and crank the engine till the
bubble free fuel flow is ensured.
7 .
Tighten all the injectors.
4 . 2 A I R C LE AN E R
4.2.1 OIL BATH TYPE AIR CLEANER
T ra ct or i s f i tt ed wi t h t wo st age (pre c leaner ( A ) and oil ba t h ty pe air
c leaner ( B ) air f il t ra t ion syst em .
If t he du st en t er in t he engine wi t h t he air i t will c au s e wear o f v ariou s
mo v ing par ts o f engine , t here f ore s hould be c leaned and s er v i c ed
depending upon t he opera t ing c ondi t ion s. Under e xt remel y du sty
c ondi t ion s t he t ime limi t re c ommend f or c leaning s hould be
de c rea s ed . P roper main t enan c e o f t he air c leaner e xt end s t he li f e o f
t he engine . Here t he air impinge s upon t he s ur f a c e f o t he oil and
par t i c le s o f f oreign ma tt er are c arried in t o t he oil b y t heir own
momen t um and t rapped .
4.2.2 CLEANING OF PRE-CLEANER (DRY)
T he f un ct ion o f pre- c leaner i s t o remo v e t he du st/ wa st e par t i c le s f rom
air be f ore en t ering t he air c leaner .
1 . Un sc rew t he c o v er nu t (C)
2 . Remo v e t he c o v er(D)
3 . T a k e ou t t he G la ss bowl( E ) , Clean i t and rea ss emble in re v er s e
pro c edure .
