SOLIS 20 User Manual

3 . 5 . 4 POWE R T AK E OFF S H IFTE R LEVE R
T here are t hree po s i t ion s f or PTO le v er . I n t he ' N ' i t i s c alled Neu t ral po s i t ion .
and o t her t hree s peed are al s o s ele ct ed b y s hi ft ing t hi s le v er t o par t i c ular
po s i t ion
PTO Lever Position
PTO RPM
@engine rated RPM
1
630
2700
2
930
3
1605
3 . 5 . 5 D IFFE R E N TI A L LO CK PE DA L
W hen y ou pre ss pedal di ff eren t ial lo ck will wor k and bo t h t he wheel ro t a t e a t
s ame s peed .
Note : Differential lock operation should be in straight position only and
should be disengaged at turnings to avoid any damage of differential
assembly.
Do not apply differential lock while tractor speed is more than 6 kmph
on turning.
3 . 5 . 6 C L U T CH PE DA L
By pre ss ing c lu tc h pedal t he mo t ion and power or engine will be di s engage
f rom gearbo x. Relea s e t he c lu tc h pedal s lowl y f or t ran sf er t he engine power
t o gear bo x.
3 . 5 . 7 M ET H O D TO CH E CK C L U T CH PE DA L F R EE PL A Y
Press down the clutch pedal and measure the distance between the footrest
and pad. The distance should be 25 to 30 mm. If the distance is less than
25 mm or higher than 30mm then get it adjusted.
NOTE: Do not keep foot on clutch pedal while tractor is in running condition. It may cause excessive wear of clutch
and clutch falls before its life time
3 . 5 . 8 FOOT BRAK E PE DA LS
U s e independen t bra k e in t he f ield opera t ion s. I n f ield y ou will t urn more
s harpl y b y pre ss ing bra k e pedal f or t he s ide wheel on t he t urn . T he pedal s
mu st be lo ck ed f or road u s e .
3.5.9 METHOD TO CHECK BRAKES
Relea s e t he hand bra k e . Un c ouple t he t wo pedal s
P re ss down t he righ t hand pedal and mea s ure t he di st an c e be t ween t he
pad s & f oo t re st. T he di st an c e s hould be be t ween 25-30 mm .
If t he f ree pla y i s le ss t han 25mm or higher t han 30mm t hen adju st t he bo t h
he x nu t on a ct ua t or t ie rod un t il f ree pla y c ome s t o 25 t o 30 mm . Now , pre ss
down t he le ft hand pedal . If t he v alue s are no t equal wi t h t he righ t hand pedal
t hen repea t t he s ame pro c edure un t il v alues c ome equal .
N OTE: E n s ure lo ck ing o f bo t h brea k padle s while dri v ing on road .
N o te: Di ff eren c e in t he f ree pla y will lead t o unbalan c ed bra k e s. t he t ra ct or c an s lew , in t he e v en t o f v iolen t bra k ing . t he
wheel on whi c h t he bra k e s are applied lo cks and t he ty re wear s ou t qui ck l y. During Road O pera t ion s B o t h t he bra k e
P edal s s hould be lo ck ed
