Sony BRAVIA KDL-55W800C User Manual

11
US
US
Connecting the TV
For more information on connections, refer
to the Help Guide.
Note
• Use an antenna cable connector no greater than
14 mm thick.
• When connecting the cable to the Cable/
A
ntenna, input finger tighten only, over
tightening the connection can damage the TV.
• Use an HDMI cable connector within 12 mm
(
thickness) × 21 mm (width).
Recommendation for an F type plug
Projection of the inner wire from the
c
onnection part must be less than 1.5 mm.
(Reference drawing for an F type plug)
1.5 mm max.
7 mm max.
Showing a Set Top Box with HDMI
connection
Set Top Box

Sony BRAVIA KDL-55W800C Specifications

General

Screen Size	55 inches
Display Type	LED
Smart TV	Yes
3D Support	Yes
HDMI Ports	4
USB Ports	3
Operating System	Android TV
Wi-Fi	Yes
Ethernet Port	Yes
Bluetooth	Yes
Sound Output	20W
Resolution	1920 x 1080
Refresh Rate	120 Hz
Weight	32.2 lbs (without stand), 33.5 lbs (with stand)
