5-15
Ref. No. Part No. Description Ref. No. Part No. Description
CCD-TRV128/TRV228/TRV228E/TRV328/TRV428/TRV428E
< FERRITE BEAD >
FB6001 1-414-760-21 FERRITE, EMI (SMD) (1608)
< IC >
IC6001 6-705-329-01 IC CM7104L42-T4
< COIL >
L6001 1-469-527-91 INDUCTOR 47uH
L6002 1-412-056-11 INDUCTOR 4.7uH
L6003 1-428-878-11 INDUCTOR 82uH
L6004 1-469-526-91 INDUCTOR 22uH
< TRANSISTOR >
Q6002 6-550-065-01 TRANSISTOR CPH5504-TL-E
< RESISTOR >
R6005 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R6009 1-218-975-11 RES-CHIP 68K 5% 1/16W
R6010 1-218-969-11 RES-CHIP 22K 5% 1/16W
R6012 1-208-707-11 METAL CHIP 10K 0.5% 1/16W
R6013 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R6014 1-218-949-11 RES-CHIP 470 5% 1/16W
R6019 1-218-990-11 SHORT CHIP 0
R6020 1-218-990-11 SHORT CHIP 0
R6026 1-218-990-11 SHORT CHIP 0
R6030 1-218-962-11 RES-CHIP 5.6K 5% 1/16W
R6031 1-218-990-11 SHORT CHIP 0
R6032 1-218-978-11 RES-CHIP 120K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB6003 1-234-372-21 RES, NETWORK 100 x 4 (1005)
< TRANSFORMER >
0 T6001 1-435-786-31 TRANSFORMER, INVERTER
A-7111-948-A PD-204 BOARD, COMPLETE (TYPE S)
***********************
< CAPACITOR >
C6001 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C6002 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C6003 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C6004 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C6005 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C6006 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C6007 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C6009 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C6010 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C6011 1-163-023-00 CERAMIC CHIP 0.015uF 10% 50V
C6012 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C6013 1-100-371-11 CERAMIC CHIP 12PF 5% 3.15KV
C6015 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C6016 1-100-249-11 CERAMIC CHIP 0.01uF 10% 16V
C6019 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C6020 1-110-457-11 ELECT CHIP 3.3uF 20% 25V
C6022 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C6024 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C6026 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C6027 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C6028 1-115-407-11 ELECT CHIP 10uF 16V
C6029 1-125-827-91 CERAMIC CHIP 1uF 10% 25V
< CONNECTOR >
CN6001 1-794-997-11 PIN, CONNECTOR 20P
CN6003 1-764-709-11 CONNECTOR, FFC/FPC (LIF) 10P
CN6004 1-815-031-11 FFC/CONNECTOR, FPC (ZIF) 24P
CN6005 1-816-176-11 CONNECTOR, FFC/FPC (ZIF) 6P
< DIODE >
D6004 8-719-988-61 DIODE 1SS355TE-17
D6006 8-719-988-61 DIODE 1SS355TE-17
D6009 8-719-071-34 DIODE RB521S-30-TE61
< FERRITE BEAD >
FB6001 1-414-760-21 FERRITE, EMI (SMD)(1608)
< IC >
IC6001 6-705-330-01 IC LRS57231
< COIL >
L6001 1-469-527-91 INDUCTOR 47uH
L6002 1-412-056-11 INDUCTOR 4.7uH
L6003 1-428-878-11 INDUCTOR 82uH
L6004 1-469-526-91 INDUCTOR 22uH
< TRANSISTOR >
Q6002 6-550-065-01 TRANSISTOR CPH5504-TL-E
Q6004 8-729-054-48 TRANSISTOR UP04601008S0
Q6005 8-729-054-48 TRANSISTOR UP04601008S0
Q6008 6-550-242-01 TRANSISTOR DTC114EMT2L
Q6009 6-550-232-01 TRANSISTOR 2SA2029T2LQ/R
< RESISTOR >
R6005 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R6009 1-218-975-11 RES-CHIP 68K 5% 1/16W
R6010 1-218-969-11 RES-CHIP 22K 5% 1/16W
R6012 1-208-707-11 METAL CHIP 10K 0.5% 1/16W
R6013 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R6014 1-218-949-11 RES-CHIP 470 5% 1/16W
R6030 1-218-962-11 RES-CHIP 5.6K 5% 1/16W
R6039 1-218-960-11 RES-CHIP 3.9K 5% 1/16W
R6040 1-218-973-11 RES-CHIP 47K 5% 1/16W
R6041 1-218-953-11 RES-CHIP 1K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB6001 1-234-378-21 RES, NETWORK 10K x 4 (1005)
RB6002 1-234-384-11 RES, NETWORK 1M x 4 (1005)
RB6003 1-234-372-21 RES, NETWORK 100 x 4 (1005)
< TRANSFORMER >
0T6001 1-435-786-31 TRANSFORMER, INVERTER
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
PD-204 (TYPE C) PD-204 (TYPE S)
