DCR-PC103E/PC104E/PC105/PC105E
MAIN PARTS
Note:
• Follow the disassembly procedure in the numerical order given.
• Items marked “*” are not stocked since they are seldom required for routine service.
Some delay should be anticipated when ordering these items.
• The parts numbers of such as a cabinet are also appeared in this section.
Refer to the parts number mentioned below the name of parts to order.
1. ORNAMENTAL PARTS
COVER
COVER
Jack cover (HP)
Note: Disassembling the main unit
is necessary to replace it.
CPC lid
(3-082-525-01)
Screw
(M1.7), lock ace, p
