Setup Menu List
107
Menu Configuration and Detailed Settings
Clock Set
Setting the built-in
clock
Date/Time Set the current time and date.
12H/24H
12H / 24H
Select the display mode of time.
12H: 12-hour mode
24H: 24-hour mode
Date Mode
YYMMDD / MMDDYY /
DDMMYY
Select the display mode of the date.
YYMMDD: In sequence of year, month, day
MMDDYY: In sequence of month, day, year
DDMMYY: In sequence of day, month, year
Language
Selecting the
language for
messages
English / Chinese / Japanese English: To display the messages in English
Chinese: To display the messages in Chinese
Japanese: To display the messages in Japaneses
Note
This setting is effective only on messages for warning and
caution. The menus and status indications do not change.
Assign Button
Assigning
functions to the
assignable buttons
<1>
Off / Marker / Last Clip DEL /
ATW / Rec Review / Rec /
Freeze Mix / Expanded Focus /
Spotlight / Backlight / IR
Remote / Shot Mark1 / Shot
Mark2 / Fader / EVF Mode /
BRT Disp / Histogram / Lens
Info
Assign a function to the ASSIGN button of the corresponding
number.
The selectable functions are common.
Marker: For turning the markers on/off
Last Clip DEL: For deleting the last recorded clip
ATW: For turning ATW on/off
Rec Review: For starting a Rec Review
Rec: For starting/stopping recording
Freeze Mix: For executing Freeze Mix
Expanded Focus: For turning Expanded Focus on/off
Spotlight: For selecting TLCS Spotlight mode
Backlight: For selecting TLCS Backlight mode
IR Remote: For activating/deactivating the IR Remote
Commander
Shot Mark1: For adding shot mark 1
Shot Mark2: For adding shot mark 2
Fader: For turning the Fader function on/off
EVF Mode: For switching between color and monochrome
modes of the EVF
BRT Disp: For turning the brightness level indication on/off
Histogram: For turning the histogram indication on/off
Lens Info: For turning the depth-of-field indication on/off
Off: No function
<2>
Off / Marker / Last Clip DEL /
ATW / Rec Review / Rec /
Freeze Mix / Expanded Focus /
Spotlight / Backlight / IR
Remote / Shot Mark1 / Shot
Mark2 / Fader / EVF Mode /
BRT Disp / Histogram / Lens
Info
<3>
Off / Marker / Last Clip DEL /
ATW / Rec Review / Rec /
Freeze Mix / Expanded Focus /
Spotlight / Backlight / IR
Remote / Shot Mark1 / Shot
Mark2 / Fader / EVF Mode /
BRT Disp / Histogram / Lens
Info
<4>
Off / Marker / Last Clip DEL /
ATW / Rec Review / Rec /
Freeze Mix / Expanded Focus /
Spotlight / Backlight / IR
Remote / Shot Mark1 / Shot
Mark2 / Fader / EVF Mode /
BRT Disp / Histogram / Lens
Info
OTHERS
Menu items Subitems and setting values Contents
