Setup Menu List

108

Menu Configuration and Detailed Settings

Tally

Setting the tally

lamps

Front

High / Low / Off

Set the brightness of the tally lamp on the front.

High: To brighten the lamp

Low: To dim the lamp

Off: To not light the lamp

Rear

On / Off

Turn the tally lamp on the rear on/off.

Hours Meter

Displaying the

hours meter

Hours (Sys) The non-resettable accumulated time of use is displayed.

Hours (Reset) The resettable accumulated time of use is displayed.

Reset

Execute/Cancel

Select “Execute” to reset the Hours (Reset) value to 0.

IR Remote

Activating/

deactivating the

Remote

Commander

On / Off Set to “On” to activate remote control operations from the

supplied IR Remote Commander.

Note

The setting automatically returns to “Off” when the

camcorder is turned off.

Battery Alarm

Setting the low

power alarm

Low BATT

5% / 10% / 15% / ... / 45% /

50%

Set the battery level at which the Low BATT warning is

generated (in steps of 5%).

BATT Empty

3% to 7% (3%)

Set the battery level at which the BATT Empty warning is

generated.

DC Low Volt1

11.5 V to 17.0 V (11.5 V)

Set the DC IN voltage at which the DC Low Volt1 warning is

generated.

DC Low Volt2

11.0 V to 14.0 V (11.0 V)

Set the DC IN voltage at which the DC Low Volt2 warning is

generated.

Battery INFO

Showing

information

regarding the

battery pack

(display only)

Type The type (product name) is displayed.

MFG Date The date of manufacture is displayed.

Charge Count The accumulated number of times of charge/discharge is

displayed.

Capacity The estimated total capacity of full charge is displayed.

Voltage The current output voltage is displayed.

Remaining The current remaining level is displayed.

Direct Menu

Setting the Direct

menu function

All / Part / Off All: All Direct menu operations are permitted.

Part: A part of Direct menu operations is permitted.

The

operation is limited depending on the GAIN, SHUTTER,

or WHITE BAL switch setting.

Off: No Direct menu operation is permitted.

i.LINK I/O

Setting for input/

output at the

i.LINK connector

Enable / Disable Enable: To use the i.LINK connector

Disable: To not use the i.LINK connector

Notes

• When you set this item to “Enable,” no signal is fed out

from the SDI OUT connector.

• When the video format is not SP mode, signal input/output

via the i.LINK connector is not enabled, even if this item is

set to “Enable.”

OTHERS

Menu items Subitems and setting values Contents
