HCD-DH50R/DH70SWR
13
2-6. FRONT PANEL BLOCK
2-7. SP-CONN BOARD
Note: This illustration sees the set from rear side.
5
two screws
(BVTT3
u
6)
6
two claws
2
flexible flat cable (7 core)
(CN510)
1
flexible flat cable (13 core)
(CN511)
3
screw
(BVTP2.6 3CR)
4
terminal
7
front panel block
1
connector
(DH50R: CN669)
(DH70SWR: CN670)
2
connector
(CN667)
4
SP-CONN board
3
two claws
