Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-DH50R/DH70SWR
8383
0 C15 1-126-964-91 ELECT 10uF 20% 50V
0 C16 1-126-963-91 ELECT 4.7uF 20% 50V
0 C17 1-162-964-91 CERAMIC CHIP 0.001uF 10% 50V
0 C18 1-115-339-91 CERAMIC CHIP 0.1uF 10% 50V
0 C19 1-115-339-91 CERAMIC CHIP 0.1uF 10% 50V
0 C20 1-126-947-91 ELECT 47uF 20% 35V
0 C21 1-115-340-91 CERAMIC CHIP 0.22uF 10% 25V
0 C22 1-107-824-81 CERAMIC 220PF 5% 1KV
0 C23 1-107-824-81 CERAMIC 220PF 5% 1KV
0 C24 1-165-610-11 FILM 0.033uF 3% 800V
0 C25 1-126-950-91 ELECT 330uF 20% 35V
0 C26 1-117-697-51 CERAMIC 470PF 10% 250V
(DH50R: TW)
0 C26 1-117-699-51 CERAMIC 0.001uF 20% 250V
(DH50R: AEP, RU, SP, KR, TH/DH70SWR)
0 C602 1-115-339-91 CERAMIC CHIP 0.1uF 10% 50V
0 C603 1-162-966-91 CERAMIC CHIP 0.0022uF 10% 50V
0 C604 1-126-960-91 ELECT 1uF 20% 50V
0 C606 1-162-970-91 CERAMIC CHIP 0.01uF 10% 25V
C901 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C902 1-137-649-31 ELECT 220uF 20% 10V
C903 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C904 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C905 1-126-916-11 ELECT 1000uF 20% 6.3V
C906 1-112-231-11 ELECT 2200uF 20% 16V
C907 1-100-924-21 ELECT 2200uF 20% 35V
C908 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C909 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C910 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C913 1-126-964-11 ELECT 10uF 20% 50V
C914 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C915 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V
C916 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C917 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C919 1-112-226-21 ELECT 470uF 20% 16V
C920 1-112-254-11 ELECT 1000uF 20% 35V
C922 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C923 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C925 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C928 1-112-212-51 ELECT 2200uF 20% 6.3V
C929 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V
C930 1-112-222-21 ELECT 2200uF 20% 10V
C931 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C932 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C933 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C943 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C944 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V
C945 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
C950 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C951 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C952 1-126-935-11 ELECT 470uF 20% 16V
C956 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
0 CN1 1-564-321-11 PIN, CONNECTOR (3.96mm PITCH) 2P
CN901 1-564-707-11 PIN, CONNECTOR (SMALL TYPE) 5P
< DIODE >
0 D1 8-719-077-77 DIODE D3SB60F3
0 D2 8-719-081-58 DIODE S2V60-TA (DH50R: TW)
0 D3 8-719-081-58 DIODE S2V60-TA (DH50R: TW)
0 D11 8-719-979-64 DIODE UF4005/23
0 D14 6-500-567-31 DIODE 10ERB20-TB3
0 D15 6-501-178-01 DIODE UDZW-TE17-15B
0 D16 6-501-178-01 DIODE UDZW-TE17-15B
0 D17 6-500-137-01 DIODE BAT54HT1
0 D602 8-719-073-23 DIODE ST02D-200TA
0 D603 6-500-567-31 DIODE 10ERB20-TB3
D901 6-500-567-31 DIODE 10ERB20-TB3
0 D902 6-500-567-31 DIODE 10ERB20-TB3
0 D903 8-719-510-09 DIODE D10SC6M
0 D904 6-501-518-01 DIODE RB085T-90
D905 8-719-982-15 DIODE MTZJ-27B
D906 6-501-778-01 DIODE MAZ8160GMLS0
D907 6-502-411-01 DIODE RL202-B322-1
0 D908 8-719-080-53 DIODE RK36LF-B3
0 D909 8-719-080-53 DIODE RK36LF-B3
D910 6-501-754-01 DIODE MAZ8091G0LS0
D911 6-501-738-01 DIODE MAZ8062GMLS0
D913 6-500-334-01 DIODE MC2836-T112-1
D914 6-501-772-01 DIODE MAZ8130GMLS0
D921 6-501-817-01 DIODE MA2J1110GLS0
D922 6-501-817-01 DIODE MA2J1110GLS0
D923 6-501-760-01 DIODE MAZ8100GMLS0
D924 6-501-817-01 DIODE MA2J1110GLS0
< FERRITE BEAD >
0 FB11 1-410-397-31 FERRITE 1.1uH
< FUSE HOLDER >
FH1 1-533-217-31 FUSE HOLDER
FH2 1-533-217-31 FUSE HOLDER
< IC >
0 IC11 6-707-749-01 IC CXD9841P
0 IC601
6-708-726-01 IC MIP2F20MS1SO
0 IC901 6-705-280-01 IC FAN431AZXA
0 IC903 8-759-474-09 IC SI-8050S-LF1101
0 IC904 8-759-474-09 IC SI-8050S-LF1101
IC905 6-705-466-01 IC BA90BC0T
IC907 6-702-302-01 IC TK11133CSCL-G
< JUMPER RESISTOR >
JR901 1-216-864-11 SHOR
T CHIP 0
JR902 1-216-864-11 SHORT CHIP 0
< COIL >
0 L901 1-412-525-41 INDUCTOR 10uH
L903 1-457-378-21 COIL, CHOKE 47uH
L904 1-457-378-21 COIL, CHOKE 47uH
< PHOTO COUPLER >
0 PH11 6-600-187-01 PHOTO COUPLER PC123Y22JOOF
0 PH601 6-600-187-01 PHOTO COUPLER PC123Y22JOOF
0 PH602 6-600-187-01 PHOTO COUPLER PC123Y22JOOF
< TRANSISTOR >
0 Q11 6-551-302-11 FET 2SK3561
0 Q12 6-551-302-11 FET 2SK3561
POW-SUPPLY
Ver. 1.1
