14
HCD-DZ555K/DZ556KB/DZ750K
3-3. FL BOARD
PRECAUTION DURING THE RETAINER (DS) INSTALLATION
(2) Route the harness as shown below. (3) Route the harness as shown below.
(1) Assemble seven claws securely.
4
shield plate (FR)
shield plate (FR)
front panel
8
FL board
FL board
JACK
board
CN806
CN805
3
five
screws
(+BVTP 2.6
×
10)
5
two
screws
(+BVTP 2.6
×
10)
1
two
rivets
6
wire (flat type)
13core (CN805)
wire (flat type) 13core
7
wire (flat type)
21core (CN801)
2
retainer (DS)
retainer (DS)
harness
rivet rivet
hole
retainer (DS)
harness
wire (flat type)
groove
groove
retainer (DS)
hole
Route the wire
(flat type) 13core
as shown in the figure.
