HCD-DZ555K/DZ556KB/DZ750K
3-17. BELT, MS-203 BOARD
1
two claws
5
three claws
7
MS-203 board
6
DC motor
3
belt
2
chuck cam
4
screw
(M 1.7
×
2.5)
