77
HCD-DZ555K/DZ556KB/DZ750K
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
FL
A-1222-520-A FL BOARD, COMPLETE (EXCEPT EA)
A-1239-705-A FL BOARD, COMPLETE (EA/DZ555K: TH)
******************
< CAPACITOR >
C435 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C436 1-115-156-11 CERAMIC CHIP 1uF 10V
C800 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C801 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
C802 1-126-947-11 ELECT 47uF 20% 35V
C803 1-126-933-11 ELECT 100uF 20% 16V
C804 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C805 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C809 1-126-157-11 ELECT 10uF 20% 16V
C811 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C814 1-126-157-11 ELECT 10uF 20% 16V
C829 1-124-259-11 ELECT 4.7uF 20% 50V
< CONNECTOR >
CN801 1-779-558-11 CONNECTOR, FFC (LIF (NON-ZIF)) 21P
(EXCEPT EA/DZ555K: TH)
CN801 1-815-387-11 CONNECTOR, FPC/FFC 21P (EA/DZ555K: TH)
CN805 1-794-506-51 CONNECTOR, FFC/FPC 13P
< DIODE >
D431 6-501-193-01 DIODE 1SS355WTE-17
D432 6-501-193-01 DIODE 1SS355WTE-17
D801 6-501-193-01 DIODE 1SS355WTE-17
D802 6-501-193-01 DIODE 1SS355WTE-17
D803 6-501-169-01 DIODE UDZW-TE17-6.2B
D804 6-501-193-01 DIODE 1SS355WTE-17
D805 6-501-193-01 DIODE 1SS355WTE-17
< IC >
IC801 6-600-349-21 IC NJL23H400A
IC802 8-759-643-83 IC uPD16315GB-3BS
< JUMPER RESISTOR >
JR801 1-216-864-11 SHORT CHIP 0
JR802 1-216-864-11 SHORT CHIP 0
JR807 1-216-864-11 SHORT CHIP 0
JR808 1-216-864-11 SHORT CHIP 0
< COIL >
L801 1-410-671-31 INDUCTOR 47uH
L802 1-410-671-31 INDUCTOR 47uH
< FLUORESCENT INDICATOR TUBE >
ND001 1-451-590-11 VACUUM FLUORESCENT DISPLAYS
< TRANSISTOR >
Q801 6-550-065-01 TRANSISTOR CPH5504-TL-E
< RESISTOR >
R436 1-216-834-11 METAL CHIP 12K 5% 1/10W
R437 1-216-835-11 METAL CHIP 15K 5% 1/10W
R800 1-216-864-11 SHORT CHIP 0
R801 1-216-839-11 METAL CHIP 33K 5% 1/10W
R802 1-216-809-11 METAL CHIP 100 5% 1/10W
R804 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R805 1-216-295-91 SHORT CHIP 0
R811 1-216-844-11 METAL CHIP 82K 5% 1/10W
R812 1-216-845-11 METAL CHIP 100K 5% 1/10W
R813 1-216-845-11 METAL CHIP 100K 5% 1/10W
R814 1-216-809-11 METAL CHIP 100 5% 1/10W
R815 1-216-809-11 METAL CHIP 100 5% 1/10W
R816 1-216-809-11 METAL CHIP 100 5% 1/10W
R819 1-216-805-11 METAL CHIP 47 5% 1/10W
R820 1-216-845-11 METAL CHIP 100K 5% 1/10W
< TRANSFORMER >
T801 1-443-645-11 TRANSFORMER, DC CONVERTER
(EA/DZ555K: TH)
T801 1-445-285-11 TRANSFORMER, DC CONVERTER
(EXCEPT EA/DZ555K: TH)
*************************************************************
A-1222-560-A IO-S-OUT BOARD, COMPLETE
(SP, AUS, E3, E12, KR, TW/DZ750K: TH)
A-1222-570-A IO-S-OUT BOARD, COMPLETE (MX, E32)
A-1239-729-A IO-S-OUT BOARD, COMPLETE (EA/DZ555K: TH)
A-1256-656-A IO-S-OUT BOARD, COMPLETE (RU)
************************
< CAPACITOR >
C211 1-126-964-11 ELECT 10uF 20% 50V
(EXCEPT MX, E32)
C222 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C228 1-126-916-11 ELECT 1000uF 20% 6.3V
C251 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C302 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C309 1-126-957-11 ELECT 0.22uF 20% 50V
C311 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C320 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
(EXCEPT MX, E32)
C321 1-104-662-91 ELECT 22uF 20% 25V
C322 1-104-662-91 ELECT 22uF 20% 25V
C324 1-104-662-91 ELECT 22uF 20% 25V
(EXCEPT MX, E32)
C327 1-104-662-91 ELECT 22uF 20% 25V
(EXCEPT MX, E32)
C328 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
(EXCEPT MX, E32)
C329 1-126-933-11 ELECT 100uF 20% 16V
C330 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C331 1-126-916-11 ELECT 1000uF 20% 6.3V
C332 1-126-933-11 ELECT 100uF 20% 16V
C333 1-126-933-11 ELECT 100uF 20% 16V
C334 1-126-916-11 ELECT 1000uF 20% 6.3V
C335 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C337 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(EXCEPT MX, E32)
C338 1-126-933-11 ELECT 100uF 20% 16V
(EXCEPT MX, E32)
C339 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C340 1-104-662-91 ELECT 22uF 20% 25V
C341 1-104-662-91 ELECT 22uF 20% 25V
C344 1-126-964-11 ELECT 10uF 20% 50V
(EXCEPT MX, E32)
C345 1-126-933-11 ELECT 100uF 20% 16V
C346 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C347 1-126-925-91 ELECT 470uF 20% 10V
IO-S-OUT
Ver. 1.3
