92
HCD-DZ555K/DZ556KB/DZ750K
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C961 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
0C963 1-117-697-51 CERAMIC 470PF 10% 250V
(EXCEPT MX, TW)
0C963 1-117-700-51 CERAMIC 0.0022uF 99% 250V
(MX, TW)
0C964 1-117-697-51 CERAMIC 470PF 10% 250V
(EXCEPT MX, TW)
0C964 1-117-700-51 CERAMIC 0.0022uF 99% 250V
(MX, TW)
C967 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C968 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C969 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C970 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C971 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C976 1-126-933-11 ELECT 100uF 20% 16V
C979 1-126-967-11 ELECT 47uF 20% 50V
(EA, E32)
0C980 1-117-828-11 FILM 3300PF 3% 1.5KV
(MX, TW)
C981 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
(EXCEPT MX, E32)
< CONNECTOR >
0CN901 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
CN903 1-564-505-11 PLUG, CONNECTOR 2P
* CN906 1-564-714-11 PIN, CONNECTOR (SMALL TYPE) 12P
CN907 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
(EXCEPT MX, E32)
< DIODE >
0D901 8-719-082-57 DIODE D5SBA60F01
0D905 8-719-063-74 DIODE D1NL20U-TR2
0D906 6-501-193-01 DIODE 1SS355WTE-17
0D907 6-501-193-01 DIODE 1SS355WTE-17
0D908 6-501-193-01 DIODE 1SS355WTE-17
0D909 6-501-193-01 DIODE 1SS355WTE-17
0D910 6-501-193-01 DIODE 1SS355WTE-17
0D913 6-500-241-01 DIODE SARS03
0D914 6-501-193-01 DIODE 1SS355WTE-17
0D915 6-501-174-01 DIODE UDZW-TE17-10B
0D921 6-501-424-01 DIODE STO2D-140
0D922 8-719-063-74 DIODE D1NL20U-TR2
0D923 6-501-174-01 DIODE UDZW-TE17-10B
0D924 6-501-183-01 DIODE UDZW-TE17-24B
0D925 6-501-167-01 DIODE UDZW-TE17-5.1B
0D926 6-501-174-01 DIODE UDZW-TE17-10B
D931 6-501-849-01 DIODE FMX-22SL
D932 6-501-167-01 DIODE UDZW-TE17-5.1B
D941 6-500-288-11 DIODE EK19LF-F7
D942 8-719-080-53 DIODE RK36LF-B3
D943 8-719-080-53 DIODE RK36LF-B3
D944 6-500-288-11 DIODE EK19LF-F7
D945 6-501-181-01 DIODE UDZW-TE17-20B
< TERMINAL GROUND >
EB901 1-537-770-21 TERMINAL BOARD, GROUND
(EXCEPT EA/DZ555K: TH)
EB901 1-537-738-21 TERMINAL, GROUND (EA/DZ555K: TH)
EB902 1-537-770-21 TERMINAL BOARD, GROUND
(EXCEPT EA/DZ555K: TH)
EB902 1-537-738-21 TERMINAL, GROUND (EA/DZ555K: TH)
EB903 1-537-770-21 TERMINAL BOARD, GROUND
(EXCEPT EA/DZ555K: TH)
EB903 1-537-738-21 TERMINAL, GROUND (EA/DZ555K: TH)
EB904 1-537-770-21 TERMINAL BOARD, GROUND
(EXCEPT EA/DZ555K: TH)
EB904 1-537-738-21 TERMINAL, GROUND (EA/DZ555K: TH)
EB906 1-537-770-21 TERMINAL BOARD, GROUND
(EXCEPT EA/DZ555K: TH)
EB906 1-537-738-21 TERMINAL, GROUND (EA/DZ555K: TH)
< FUSE HOLDER >
FH901 1-533-217-41 HOLDER, FUSE
FH902 1-533-217-41 HOLDER, FUSE
< FUSIBLE RESISTOR >
0 FR901 1-242-949-11 FUSIBLE 0.1 10% 1W
(SP, AUS, E3, E12, KR, RU, TH)
< IC >
0 IC901 6-707-741-01 IC STR-F6138-LF1352 (MX, TW)
0 IC901 6-707-742-01 IC STR-F6168-LF1352 (EXCEPT MX, TW)
0 IC921 6-707-740-01 IC STR-V153
IC931 8-759-648-34 IC TA76431AS (TPE6)
IC941 6-705-308-01 IC SI-3010KM-TL
IC942 6-705-308-01 IC SI-3010KM-TL
IC943 6-705-308-01 IC SI-3010KM-TL
IC951 6-707-743-01 IC TA76L431S (TPE6, Q)
< COIL >
L931 1-457-438-11 INDUCTOR 5.6uH
L941 1-414-398-11 INDUCTOR 10uH
L942 1-414-398-11 INDUCTOR 10uH
L943 1-414-398-11 INDUCTOR 10uH
L944 1-414-398-11 INDUCTOR 10uH
L945 1-414-398-11 INDUCTOR 10uH
L947 1-414-398-11 INDUCTOR 10uH
L948 1-414-398-11 INDUCTOR 10uH
L951 1-414-398-11 INDUCTOR 10uH
L952 1-414-398-11 INDUCTOR 10uH
< LINE FILTER >
0 LF901 1-457-054-21 COIL, LINE FILTER
0 LF902 1-457-054-21 COIL, LINE FILTER
< PHOTO COUPLER >
0 PC901 6-600-438-01 IC TLP421F (D4-GR)
0 PC902 6-600-438-01 IC TLP421F (D4-GR)
0 PC903 6-600-438-01 IC TLP421F (D4-GR)
< TRANSISTOR >
0 Q901 8-729-141-88 TRANSISTOR 2SB1116A-TP-LK
0 Q921 8-729-142-51 TRANSISTOR 2SD1616A-TP-LK
Q943 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q945 6-550-718-01 TRANSISTOR RSR025N03TL
Q947 8-729-038-28 TRANSISTOR RT1N441C-TP-1
< RESISTOR >
0 R901 1-219-759-11 METAL 1M 5% 1/2W
0 R903 1-215-926-00 METAL OXIDE 33K 5% 3W
(MX, TW)
POWER
Ver. 1.3
