HCD-DZ265K/DZ266K/DZ270K/DZ570K/DZ777K
HCD-DZ265K/DZ266K/DZ270K/DZ570K/DZ777K
3232
• Waveforms
– MAIN Board – – IO-COMPONENT Board –
 IC1101  (DVDRFIP)
200 mV/DIV, 100 ns/DIV
 IC1101 [Y (R/Cr/Pr)
500 mV/DIV, 20 μs/DIV
 IC1101 [D (B/Cb/Pb)
500 mV/DIV, 20 μs/DIV
 IC1101 [C (Y/G)
1 V/DIV, 20 μs/DIV
 IC1101 [ (C)
1 V/DIV, 20 μs/DIV
 IC1101 [[ (Y)
1 V/DIV, 20 μs/DIV
 IC1101 YD (XTALO)
500 mV/DIV, 20 ns/DIV
 IC501 RE (Xout)
1 V/DIV, 100 ns/DIV
 IC3010 RG (XFSOOUT)
1 V/DIV, 10 ns/DIV
 IC3010 SL (XFSOIN)
1 V/DIV, 10 ns/DIV
RB IC3051  (3Y)
1 V/DIV, 10 ns/DIV
0.72Vp-p
0.72Vp-p
H
1Vp-p
H
1Vp-p
H
H
1Vp-p
4.3Vp-p
49.1MHz
1.6Vp-p
27MHz
4.3Vp-p
49.1MHz
4.3Vp-p
49.1MHz
3.4Vp-p
5MHz
650mVp-p
H
 IC404  (Cin)
1 V/DIV, 20 μs/DIV
 IC404  (Yin)
1 V/DIV, 20 μs/DIV
 IC404  (CYin)
1 V/DIV, 20 μs/DIV
 IC404 RT (Cb in)
500 mV/DIV, 20 μs/DIV
 IC404 RG (Cr in)
500 mV/DIV, 20 μs/DIV
 IC404 X (CY OUT)
1 V/DIV, 20 μs/DIV
 IC404 RL (Cb OUT)
500 mV/DIV, 20 μs/DIV
 IC404 RI (Cr OUT)
500 mV/DIV, 20 μs/DIV
 IC404 XE (CVBS OUT)
500 mV/DIV, 20 μs/DIV
0.72Vp-p
0.72Vp-p
H
1Vp-p
H
1Vp-p
H
H
1Vp-p
H
0.72Vp-p
0.72Vp-p
H
1Vp-p
H
H
H
1.3Vp-p
