HCD-DZ265K/DZ266K/DZ270K/DZ570K/DZ777K
63
IC507 TK11150CSCL-G (MAIN Board (5/9))
IC1105 TK11133CSCL-G (MAIN Board (1/9))
IC1107 TK11133CSCL-G (MAIN Board (1/9))
IC1707 TK11150CSCL-G (MAIN Board (3/9))
IC1708 TK11133CSCL-G (MAIN Board (3/9))
IC3050 TK11118CSCL-G (MAIN Board (9/9))
1 2 3
5 4
CONT
GND
NOISE/NP
VIN VOUT
CONTROL
CIRCUIT
OVER HEAT &
OVER CURRENT
PROTECTION
BANDGAP
REFERENCE
