Sony HCD-DZ777K User Manual

HCD-DZ265K/DZ266K/DZ270K/DZ570K/DZ777K
67
IC901 STR-F6138-LF1352 (POWER Board)
OCP/INH
1
GND
2
D
3
VCC
4
FB/OLP
5
+
–
+
–
+
–
+
–
+
–
Delay
OVP
TSD
Delay
Reg2
Reg1
Reg3
Current mirror
POWER
MOS FET
Latch
OSC
Boottom Skip
Logic
OCP2
Logic
Internal
Bias
OCP1
Vocp
Rg3
Rg2
Rg1
OCP2
+
–
UVL0
ON=16V
OFF=10.5V
INH1
INH2
FB
Vth1
+
–
IOLP
Volp
Vth2
Vocp(BSIN,OUT)
IC941 SI-3010KM-TL (POWER Board)
IC201 SI-3010KM-TL (MAIN Board (6/9)) (DZ570K/DZ777K)
IC504 SI-3010KM-TL (MAIN Board (5/9))
IC505 SI-3010KM-TL (MAIN Board (5/9))
IC506 SI-3010KM-TL (MAIN Board (5/9))
TSD
REF
4
3
2
15
+
–
VOUT GND
VIN
VCONT SENSE
