Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-DZ265K/DZ266K/DZ270K/DZ570K/DZ777K
9595
< JUMPER RESISTOR >
JR451 1-216-864-11 SHORT CHIP 0
JR452 1-216-864-11 SHORT CHIP 0
JR453 1-216-864-11 SHORT CHIP 0
< RESISTOR >
R302 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R303 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R304 1-216-821-11 METAL CHIP 1K 5% 1/10W
R305 1-216-845-11 METAL CHIP 100K 5% 1/10W
R306 1-216-845-11 METAL CHIP 100K 5% 1/10W
R307 1-216-821-11 METAL CHIP 1K 5% 1/10W
R308 1-216-821-11 METAL CHIP 1K 5% 1/10W
R309 1-216-851-11 METAL CHIP 330K 5% 1/10W
R310 1-216-853-11 METAL CHIP 470K 5% 1/10W
R311 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R312 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R313 1-216-841-11 METAL CHIP 47K 5% 1/10W
R314 1-216-841-11 METAL CHIP 47K 5% 1/10W
R319 1-216-842-11 METAL CHIP 56K 5% 1/10W
R320 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R322 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R323 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R324 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R325 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R326 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R327 1-216-837-11 METAL CHIP 22K 5% 1/10W
R328 1-216-833-11 METAL CHIP 10K 5% 1/10W
R329 1-216-833-11 METAL CHIP 10K 5% 1/10W
R330 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R334 1-216-864-11 SHORT CHIP 0
R336 1-216-864-11 SHORT CHIP 0
*************************************************************
SPEAKER BOARD
**************
< CAPACITOR >
C173 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
(RU,EA)
C174 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C175 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
(RU,EA)
C176 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C177 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
(RU,EA)
C178 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C179 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
(RU,EA)
C180 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C181 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
(RU,EA)
C182 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C183 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
(RU,EA)
C184 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C185 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
(RU,EA)
C186 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C187 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
(RU,EA)
C188 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
* CN114 1-564-523-11 PLUG, CONNECTOR 8P
< TERMINAL BOARD >
TB100 1-780-454-11 TERMINAL BOARD (SPEAKER) 4P (SPEAKER
(FRONT R,FRONT L,SUR R,SUR L))
*************************************************************
MISCELLANEOUS
**************
4 1-827-720-11 WIRE (FLAT TYPE) (11 CORE) (DZ265K/DZ266K)
4 1-828-955-11 WIRE (FLAT TYPE) (9 CORE)
(DZ270K/DZ570K/DZ777K)
0 5 1-834-288-11 CORD, POWER (TH)
0 5 1-834-966-21 CORD, POWER (EXCEPT TH)
0 7 1-770-019-61 ADAPTOR, CONVERSION PLUG (EA)
11 1-828-350-11 WIRE (FLAT TYPE) (17 CORE) (DZ570K/DZ777K)
0 13 1-569-008-22 ADAPTOR, CONVERSION 2P (EA)
63 1-828-307-11 WIRE (FLAT TYPE) (9 CORE)
64 1-828-363-11 WIRE (FLAT TYPE) (19 CORE)
106 1-828-293-11 WIRE (FLAT TYPE) (5 CORE)
107 1-828-359-11 WIRE (FLAT TYPE) (19 CORE)
(DZ270K/DZ570K/DZ777K)
107 1-828-369-11 WIRE (FLAT TYPE) (21 CORE) (DZ265K/DZ266K)
108 1-828-337-11 WIRE (FLAT TYPE) (15 CORE)
(DZ265K/DZ266K/DZ270K)
108 1-828-347-11 WIRE (FLAT TYPE) (17 CORE) (DZ570K/DZ777K)
114 1-828-296-11 WIRE (FLAT TYPE) (7 CORE)
0 157 8-820-321-05 OPTICAL PICK-UP KHM-313CAA/C2RP
158 1-828-773-51 WIRE (FLAT TYPE) (24 CORE)
0 F901 1-576-233-51 FUSE (H.B.C.) (T6.3HA/250V) (EXCEPT EA)
0 F901 1-576-300-51 FUSE, H.B.C. (T8HA/250V) (EA)
FAN901 1-787-331-11 FAN, D.C.
TU901 1-693-759-11 TUNER (FM/AM) (DZ265K/DZ266K)
TU901 1-693-761-11 TUNER (FM/AM) (DZ270K/DZ570K/DZ777K)
