Sony HCD-F200 Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-F200/F500
68
FB602 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB603 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB604 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB605 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB606 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB1101 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB1103 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB1104 1-469-379-11 FERRITE, EMI (SMD) (2012)
FB1120 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB1121 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB1122 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB1124 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB1125 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB3901 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB3902 1-469-324-21 FERRITE, EMI (SMD) (2012)
< FILTER >
FL601 1-234-494-21 FILTER, EMI REMOVAL (SMD)
FL602 1-233-893-21 FILTER, CHIP EMI
FL603 1-234-494-21 FILTER, EMI REMOVAL (SMD)
FL3901 1-234-494-21 FILTER, EMI REMOVAL (SMD)
< IC >
IC101 6-711-269-01 IC CXD9894R (EXCEPT F500: CND)
IC101 6-711-557-01 IC CXD9915R (F500: CND)
IC102 (Not supplied)
IC ES29LV320EB70TG-SHE1-0802CE
(F200: AEP, UK)
IC102 (Not supplied) IC ES29LV320EB70TG-SHE1-0802GA
(F200: SP, TH)
IC102 (Not supplied) IC ES29LV320EB70TG-SHE2-0802UC
(F500: CND, E32, MX)
IC102 (Not supplied) IC ES29LV320EB70TG-SHE2-0802CE
(F500: RU, E3, E15, EA, AUS)
IC102 (Not supplied) IC ES29LV320EB70TG-SHE2-0802GA
(F500: SP, TW, KR, TH)
IC103 (Not supplied) IC S-24CS64A01-J8T1G
IC104 6-709-737-01 IC M12L64164A-7T (G)
IC105 6-702-302-01 IC TK11133CSCL-G
IC107 6-702-302-01 IC TK11133CSCL-G
IC110 6-707-739-01 IC MM1661JTRE
IC201 6-704-524-01 IC FAN8036L
IC705 8-759-592-47 IC TC7SZ08FU (TE85R)
IC707 6-705-337-01 IC TK11150CSCL-G
IC708 6-702-302-01 IC TK11133CSCL-G
IC3001 8-759-592-47 IC TC7SZ08FU (TE85R) (F500)
IC3801 8-759-710-97 IC NJM4565M-D
< COIL >
* L701 1-813-308-11 COMMON MODE CHOKE
* L702
1-813-308-11 COMMON MODE CHOKE
* L703 1-813-308-11 COMMON MODE CHOKE
* L704 1-813-308-11 COMMON MODE CHOKE
L1101 1-456-799-11 COIL, COMMON MODE CHOKE
L3801 1-469-525-91 INDUCTOR 10uH
< TRANSISTOR >
Q101 6-550-008-01 FET UM6K1N-TN
Q102 6-550-653-01 TRANSISTOR QST8TR
Q103 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q105 8-729-028-27 FET 2SK2009 (TE85L)
Q701 6-550-008-01 FET UM6K1N-TN
Q9724 6-551-699-01 TRANSISTOR ISA1602AM1TP-1EF
Q9726 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q9728 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q9729 8-729-027-43 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R101 1-216-809-11 METAL CHIP 100 5% 1/10W
R102 1-216-864-11 SHORT CHIP 0
R103 1-218-864-11 METAL CHIP 5.1K 0.5% 1/10W
R105 1-216-833-11 METAL CHIP 10K 5% 1/10W
R106 1-216-833-11 METAL CHIP 10K 5% 1/10W
R107 1-216-833-11 METAL CHIP 10K 5% 1/10W
R108 1-216-857-11 METAL CHIP 1M 5% 1/10W
R109 1-216-864-11 SHORT CHIP 0
R110 1-216-841-11 METAL CHIP 47K 5% 1/10W
R111 1-216-809-11 METAL CHIP 100 5% 1/10W
R112 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R113 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R114 1-216-845-11 METAL CHIP 100K 5% 1/10W
R115 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R116 1-216-821-11 METAL CHIP 1K 5% 1/10W
R117 1-216-841-11 METAL CHIP 47K 5% 1/10W
R118 1-216-801-11 METAL CHIP 22 5% 1/10W
R120 1-216-801-11 METAL CHIP 22 5% 1/10W
R121 1-216-801-11 METAL CHIP 22 5% 1/10W
R123 1-216-864-11 SHORT CHIP 0
R124 1-216-841-11 METAL CHIP 47K 5% 1/10W
R132 1-216-845-11 METAL CHIP 100K 5% 1/10W
R133 1-216-864-11 SHORT CHIP 0
R135 1-216-821-11 METAL CHIP 1K 5% 1/10W
R136 1-216-835-11 METAL CHIP 15K 5% 1/10W
R139 1-216-864-11 SHORT CHIP 0
R140 1-216-821-11 METAL CHIP 1K 5% 1/10W
R141 1-216-855-11 METAL CHIP 680K 5% 1/10W
R142 1-216-845-11 METAL CHIP 100K 5% 1/10W
R151 1-216-833-11 METAL CHIP 10K 5% 1/10W
R152 1-216-864-11 SHORT CHIP 0
R153 1-216-864-11 SHORT CHIP 0
R154 1-216-864-11 SHORT CHIP 0
R155 1-216-864-11 SHORT CHIP 0
R156 1-216-809-11 METAL CHIP 100 5% 1/10W
R171 1-216-809-11 METAL CHIP 100 5% 1/10W
R175 1-216-864-11 SHORT CHIP 0
R179 1-216-864-11 SHORT CHIP 0
R180 1-216-864-11 SHORT CHIP 0
R189 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R190 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R191 1-216-821-11 METAL CHIP 1K 5% 1/10W
R193 1-216-821-11 METAL CHIP 1K 5% 1/10W
R195 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R197 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R198 1-216-809-11 METAL CHIP 100 5% 1/10W
R204 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R205 1-216-833-11 METAL CHIP 10K 5% 1/10W
R206 1-216-833-11 METAL CHIP 10K 5% 1/10W
R207 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R208 1-216-839-11 METAL CHIP 33K 5% 1/10W
R209 1-216-839-11 METAL CHIP 33K 5% 1/10W
R210 1-216-841-11 METAL CHIP 47K 5% 1/10W
R212 1-216-833-11 METAL CHIP 10K 5% 1/10W
Note: IC102 and IC103 cannot exchange with single. When IC102 and
IC103 are damaged, exchange the entire mounted board.
DMB-FIT
Ver. 1.1
