Sony HCD-FX205 Service Manual

36
HCD-FX200/FX205
SECTION 7
ELECTRICAL PARTS LIST
A-1748-698-A BD73U BOARD, COMPLETE
**********************
< CAPACITOR >
C101 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C102 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C103 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C104 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C105 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C106 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C107 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C108 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C110 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C111 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C112 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C113 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C116 1-128-995-21 ELECT CHIP 100uF 20% 10V
C117 1-100-756-91 CERAMIC CHIP 0.047uF 10% 50V
C118 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C119 1-128-995-21 ELECT CHIP 100uF 20% 10V
C120 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C121 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C122 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C123 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C124 1-128-995-21 ELECT CHIP 100uF 20% 10V
C125 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C126 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C127 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C128 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C129 1-128-995-21 ELECT CHIP 100uF 20% 10V
C130 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C131 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C132 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C133 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C136 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C201 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C203 1-137-710-91 CERAMIC CHIP 10uF 20% 6.3V
C205 1-137-710-91 CERAMIC CHIP 10uF 20% 6.3V
C206 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C207 1-128-995-21 ELECT CHIP 100uF 20% 10V
C208 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C209 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C301 1-128-394-11 ELECT CHIP 220uF 20% 10V
C302 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C303 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C304 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C401 1-128-995-21 ELECT CHIP 100uF 20% 10V
C402 1-128-995-21 ELECT CHIP 100uF 20% 10V
C403 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C404 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C408 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C409 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C410 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C413 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C414 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
< CONNECTOR >
CN201 1-770-425-51 CONNECTOR, FFC/FPC 16P
CN402 1-784-871-51 CONNECTOR, FFC (LIF (NON-ZIF)) 19P
< IC >
IC101 6-714-785-01 IC LC786924NT-US-H
IC301 6-710-637-01 IC BA5826HFP-E2
< TRANSISTOR >
Q201 6-551-120-01 TRANSISTOR 2SA2119K
< RESISTOR >
R101 1-216-815-11 METAL CHIP 330 5% 1/10W
R102 1-216-833-11 METAL CHIP 10K 5% 1/10W
R103 1-216-864-11 SHORT CHIP 0
R104 1-216-864-11 SHORT CHIP 0
R105 1-216-864-11 SHORT CHIP 0
R106 1-216-864-11 SHORT CHIP 0
R107 1-216-843-11 METAL CHIP 68K 5% 1/10W
R108 1-216-821-11 METAL CHIP 1K 5% 1/10W
R109 1-216-821-11 METAL CHIP 1K 5% 1/10W
R111 1-216-837-11 METAL CHIP 22K 5% 1/10W
R112 1-216-864-11 SHORT CHIP 0
R113 1-216-819-11 METAL CHIP 680 5% 1/10W
R114 1-216-819-11 METAL CHIP 680 5% 1/10W
R116 1-216-843-11 METAL CHIP 68K 5% 1/10W
R117 1-216-833-11 METAL CHIP 10K 5% 1/10W
R118 1-216-809-11 METAL CHIP 100 5% 1/10W
R120 1-216-833-11 METAL CHIP 10K 5% 1/10W
R121 1-216-833-11 METAL CHIP 10K 5% 1/10W
R122 1-216-833-11 METAL CHIP 10K 5% 1/10W
R123 1-216-833-11 METAL CHIP 10K 5% 1/10W
R124 1-216-833-11 METAL CHIP 10K 5% 1/10W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
BD73U
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Abbreviation
AR : Argentina model
AUS : Australian model
E2 : 120V AC area in E model
E51 : Chilean and Peruvian models
EA : Saudi Arabia model
KR : Korean model
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
RU : Russian model
SP : Singapore model
TH : Thai model
TW : Taiwan model
Ver. 1.1
